Product Description
| |
 |
| Spedometer |
| |
| Combination of digital and monolog |
|
|
|
|
 |
| Headlamp |
| |
| Classic Design Headlamp |
|
|
|
|
 |
| Suspension |
| |
| Double Suspension with heavy duty and better absorption |
|
|
|
|
|
| |
 |
| Engine |
| |
| 149cc,Single Cylinder,4-Stroke and 2-Valve Engine |
|
|
|
|
|
| |
 |
|
click me to view colors |
|
|
|
|
|
|
|
| |
Specification
|
| |
| ENGINE |
|
| |
 |
|
TYPE |
| |
|
1-Cylinder, 4 Stroke, SOHC, Air Cooled |
| |
|
|
MAX TORQUE |
| |
|
11.1 N.m @ 6,000 rpm |
| |
|
|
LUBRICATION SYSTEM |
| |
|
Pressure splash |
| |
|
|
IGNITION |
| |
|
C.D.I |
| |
|
|
BORE X STROKE |
| |
|
62 x 49.5mm |
|
|
|
|
COMPRESSION RATIO |
| |
|
9.3:1 |
| |
|
|
CLUTCH TYPE |
| |
|
Wet Multiple Plate |
| |
|
|
DISPLACEMENT |
| |
|
149 c.c. |
| |
|
|
FUEL SYSTEM |
| |
|
Carburetor |
| |
|
|
FINAL DRIVE TYPE |
| |
|
Chain |
|
|
|
|
MAX POWER |
| |
|
8.4 kW @ 8,000 rpm |
| |
|
|
TRANSMISSION |
| |
|
5 Speed, Constant Mesh |
| |
|
|
STARTER |
| |
|
Electric & Kick |
|
|
| |
| CHASIS |
|
| |
|
|
FRAME TYPE |
| |
|
Bassinet type |
| |
|
|
REAR BRAKE |
| |
|
Drum |
| |
|
|
SEAT HEIGHT (MM) |
| |
|
770 |
| |
|
|
GROUND CLEARANCE (MM) |
| |
|
160 |
| |
|
|
FRONT SUSPENSION |
| |
|
Telescopic Forks |
|
|
|
|
FRONT TYRE |
| |
|
2.75-17 |
| |
|
|
OVERALL LENGTH (MM) |
| |
|
1,930 |
| |
|
|
FUEL CAPACITY (LITER) |
| |
|
12.1 |
| |
|
|
REAR SUSPENSION |
| |
|
Shock Absorber |
| |
|
|
REAR TYRE |
| |
|
90/90-17 |
|
|
|
|
OVERALL WIDTH (MM) |
| |
|
786 |
| |
|
|
BATTERY |
| |
|
12V-5Ah |
| |
|
|
FRONT BRAKE |
| |
|
Disc |
| |
|
|
DRY WEIGHT (KG) |
| |
|
108 |
| |
|
|
WHEELBASE (MM) |
| |
|
1,270 |
|
|
| |
